HX5100系列电子移相器可单独销售，用于各种应用。它们被设计成与Holzworth HA7000系列相位噪声分析仪配对使用。这些移相器是频率特定的，允许使用Holzworth相位噪声测试系统实现附加/残余相位噪声测量的完全自动化。
主要性能指标：
| 型号 | 频率 (fc) | 带宽 | 移相范围 | 附加相位噪声 |
|---|
| HX5100-17M | 17MHz | 10MHz - 23MHz | 0 to >180 deg | < -175dBc/Hz (typical) Input Referred |
| HX5100-35M | 35MHz | 23MHz - 47MHz | 0 to >180 deg | < -175dBc/Hz (typical) Input Referred |
| HX5100-70M | 70MHz | 47MHz - 94MHz | 0 to >180 deg | < -175dBc/Hz (typical) Input Referred |
| HX5100-140M | 140MHz | 94MHz - 187MHz | 0 to >180 deg | < -175dBc/Hz (typical) Input Referred |
| HX5100-280M | 280MHz | 187MHz - 375MHz | 0 to >180 deg | < -175dBc/Hz (typical) Input Referred |
| HX5100-500M | 500MHz | 375MHz - 750MHz | 0 to >180 deg | < -175dBc/Hz (typical) Input Referred |
| HX5100-1000M | 1000MHz | 750MHz - 1.5GHz | 0 to >180 deg | < -175dBc/Hz (typical) Input Referred |
| HX5100-2250M | 2250MHz | 1.5GHz - 3GHz | 0 to >180 deg | < -175dBc/Hz (typical) Input Referred |
| HX5100-4500M | 4500MHz | 3GHz - 6GHz | 0 to >180 deg | < -175dBc/Hz (typical) Input Referred |
| HX5100-0616 | 11GHz | 6GHz - 16GHz | 0 to >180 deg | < -175dBc/Hz (typical) Input Referred |
| HX5100-1424 | 19GHz | 14GHz - 24GHz | 0 to >180 deg | < -175dBc/Hz (typical) Input Referred |
| HX5100-x | 联系Holzworth或者当地授权代理商 |
HX5100配合HA7000系列相噪分析仪做附件相位噪声测试
订货信息：
HX5100-17M 10MHz-23MHz移相器模块
HX5100-35M 23MHz-47MHz移相器模块
HX5100-70M 47MHz-94MHz移相器模块
HX5100-140M 94MHz-187MHz移相器模块
HX5100-280M 187MHz-375MHz移相器模块
HX5100-500M 375MHz-750MHz移相器模块
HX5100-1000M 750MHz-1.5GHz移相器模块
HX5100-2250M 1.5GHz-3GHz移相器模块
HX5100-4500M 3GHz-6GHz移相器模块
HX5100-0616 6GHz-16GHz移相器模块
HX5100-1424 14GHz-24GHz移相器模块
